ZeroDExpChannel

Classes

ZeroDExpChannel

Inheritance diagram of ZeroDExpChannel
class ZeroDExpChannel(dclass, name)[source]

Bases: PoolExpChannelDevice

init(name)[source]

initialize the device once in the object lifetime. Override when necessary but always call the method from your super class

:param str name: device name

get_zerod()[source]
set_zerod(zerod)[source]
property zerod
delete_device(*args, **kwargs)[source]

Clean the device. Called during shutdown and every time the tango Init command is executed. Override when necessary but always call the method from your super class

init_device(*args, **kwargs)[source]

Initialize the device. Called during startup after init() and every time the tango Init command is executed. Override when necessary but always call the method from your super class

on_zerod_changed(event_source, event_type, event_value)[source]
always_executed_hook(self)[source]

Hook method.

Default method to implement an action necessary on a device before any command is executed. This method can be redefined in sub-classes in case of the default behaviour does not fullfill the needs

Raises:

DevFailed – This method does not throw exception but a redefined method can.

get_dynamic_attributes()[source]

Override of PoolDevice.get_dynamic_attributes. Returns the standard dynamic and fully dynamic attributes for this device. The return is a tuple of two dictionaries:

  • standard attributes: caseless dictionary with key being the attribute name and value is a tuple of attribute name(str), tango information, attribute information

  • dynamic attributes: caseless dictionary with key being the attribute name and value is a tuple of attribute name(str), tango information, attribute information

tango information

seq< CmdArgType, AttrDataFormat, AttrWriteType >

attribute information

attribute information as returned by the sardana controller

Returns:

the standard dynamic and fully dynamic attributes

Return type:

seq< CaselessDict, CaselessDict>

initialize_dynamic_attributes()[source]

Initializes this device dynamic attributes

read_Value(attr)[source]
read_CurrentValue(attr)[source]
Start()[source]
read_AccumulationBuffer(attr)[source]
read_TimeBuffer(attr)[source]
read_AccumulationType(attr)[source]
write_AccumulationType(attr)[source]
is_Value_allowed(req_type)

Generic is_allowed

is_CurrentValue_allowed(req_type)

Generic is_allowed

is_AccumulationType_allowed(req_type)

Generic is_allowed

is_AccumulationBuffer_allowed(req_type)

Generic is_allowed

is_TimeBuffer_allowed(req_type)

Generic is_allowed

ZeroDExpChannelClass

Inheritance diagram of ZeroDExpChannelClass
class ZeroDExpChannelClass(name)[source]

Bases: PoolExpChannelDeviceClass

class_property_list = {}

Sardana device class properties definition

device_property_list = {'Axis': [tango._tango.CmdArgType.DevLong64, 'Axis in the controller', [0]], 'Ctrl_id': [tango._tango.CmdArgType.DevString, 'Controller ID', [0]], 'Force_HW_Read': [tango._tango.CmdArgType.DevBoolean, 'Force a hardware read of value even when in operation (motion/acquisition', False], 'Id': [tango._tango.CmdArgType.DevLong64, 'Internal ID', 0], 'Instrument_id': [tango._tango.CmdArgType.DevString, 'Instrument ID', [0]]}

Sardana device properties definition

cmd_list = {'Abort': [[tango._tango.CmdArgType.DevVoid, ''], [tango._tango.CmdArgType.DevVoid, '']], 'Release': [[tango._tango.CmdArgType.DevVoid, ''], [tango._tango.CmdArgType.DevVoid, '']], 'Restore': [[tango._tango.CmdArgType.DevVoid, ''], [tango._tango.CmdArgType.DevVoid, '']], 'Start': [[tango._tango.CmdArgType.DevVoid, ''], [tango._tango.CmdArgType.DevVoid, '']], 'Stop': [[tango._tango.CmdArgType.DevVoid, ''], [tango._tango.CmdArgType.DevVoid, '']]}

Sardana device command definition

attr_list = {'AccumulationBuffer': [[tango._tango.CmdArgType.DevDouble, tango._tango.AttrDataFormat.SPECTRUM, tango._tango.AttrWriteType.READ, 16384]], 'AccumulationType': [[tango._tango.CmdArgType.DevString, tango._tango.AttrDataFormat.SCALAR, tango._tango.AttrWriteType.READ_WRITE], {'Memorized': 'true_without_hard_applied', 'label': 'Accumulation Type', 'Display level': tango._tango.DispLevel.EXPERT}], 'Instrument': [[tango._tango.CmdArgType.DevString, tango._tango.AttrDataFormat.SCALAR, tango._tango.AttrWriteType.READ_WRITE], {'label': 'Instrument', 'Display level': tango._tango.DispLevel.EXPERT}], 'IntegrationTime': [[tango._tango.CmdArgType.DevDouble, tango._tango.AttrDataFormat.SCALAR, tango._tango.AttrWriteType.READ_WRITE]], 'SimulationMode': [[tango._tango.CmdArgType.DevBoolean, tango._tango.AttrDataFormat.SCALAR, tango._tango.AttrWriteType.READ_WRITE], {'label': 'Simulation mode'}], 'TimeBuffer': [[tango._tango.CmdArgType.DevDouble, tango._tango.AttrDataFormat.SPECTRUM, tango._tango.AttrWriteType.READ, 16384]]}

Sardana device attribute definition

standard_attr_list = {'Shape': [[tango._tango.CmdArgType.DevLong64, tango._tango.AttrDataFormat.SPECTRUM, tango._tango.AttrWriteType.READ, 2], {'label': 'Shape (X,Y)', 'description': 'Shape of the value. It is an array with \nat most 2 elements: X and Y dimensions. \n0-element array - scalar\n1-element array (X) - spectrum\n2-element array (X, Y) - image'}], 'Value': [[tango._tango.CmdArgType.DevVoid, tango._tango.AttrDataFormat.SCALAR, tango._tango.AttrWriteType.READ], {'abs_change': '1.0'}], 'ValueBuffer': [[tango._tango.CmdArgType.DevEncoded, tango._tango.AttrDataFormat.SCALAR, tango._tango.AttrWriteType.READ]]}
