Pool

Classes

Pool

Inheritance diagram of Pool
class Pool(cl, name)[source]

Bases: LatestDeviceImpl, Logger

ElementsCache = None
init(full_name)[source]
get_full_name()[source]

Compose full name from the TANGO_HOST information and device name.

In case Sardana is used with Taurus 3 the full name is of format “dbhost:dbport/<domain>/<family>/<member>” where dbhost may be either FQDN or PQDN, depending on the TANGO_HOST configuration.

In case Sardana is used with Taurus 4 the full name is of format “tango://dbhost:dbport/<domain>/<family>/<member>” where dbhost is always FQDN.

Return type:

str

Returns:

this device full name

property pool
delete_device(self)[source]

Delete the device.

init_device(self)[source]

Intialize the device.

always_executed_hook(self)[source]

Hook method.

Default method to implement an action necessary on a device before any command is executed. This method can be redefined in sub-classes in case of the default behaviour does not fullfill the needs

Raises:

DevFailed – This method does not throw exception but a redefined method can.

read_ControllerLibList(attr)[source]
read_ControllerClassList(attr)[source]
read_ControllerList(attr)[source]
read_InstrumentList(attr)[source]
read_ExpChannelList(attr)[source]
read_AcqChannelList(attr)[source]
read_MotorGroupList(attr)[source]
read_MotorList(attr)[source]
read_TriggerGateList(attr)[source]
read_MeasurementGroupList(attr)[source]
read_IORegisterList(attr)[source]
read_ComChannelList(attr)[source]
getElements(cache=True)[source]
read_Elements(attr)[source]
is_Elements_allowed(req_type)[source]
is_ControllerLibList_allowed(req_type)
is_ControllerClassList_allowed(req_type)
is_ControllerList_allowed(req_type)
is_InstrumentList_allowed(req_type)
is_ExpChannelList_allowed(req_type)
is_TriggerGateList_allowed(req_type)
is_AcqChannelList_allowed(req_type)
is_MotorGroupList_allowed(req_type)
is_MotorList_allowed(req_type)
is_MeasurementGroupList_allowed(req_type)
is_IORegisterList_allowed(req_type)
is_ComChannelList_allowed(req_type)
CreateController(argin)[source]

Tango command to create controller.

Parameters:

argin (list<str>) –

Must give either:

  • A JSON encoded dict as first string with:
    • mandatory keys: ‘type’, ‘library’, ‘klass’ and ‘name’ (values are strings).

    • optional keys:
      • ’properties’: a dict with keys being property names and values the property values

      • ’roles’: a dict with keys being controller roles and values being element names. (example: { ‘gap’ : ‘motor21’, ‘offset’ : ‘motor55’ }). Only applicable of pseudo controllers

  • a sequence of strings: <type>, <library>, <class>, <name> [, <role_name>’=’<element name>] [, <property name>, <property value>]

Examples:

data = dict(type='Motor', library='DummyMotorController',
            klass='DummyMotorController',
            name='my_motor_ctrl_1')
pool.CreateController([json.dumps(data)])

pool.CreateController(['Motor', 'DummyMotorController', 'DummyMotorController',
                       'my_motor_ctrl_2'])

Returns:

None

CreateInstrument(argin)[source]

Tango command to create instrument.

Parameters:

argin (list<str>) –

Must give either:

  • A JSON encoded dict as first string with:
    • mandatory keys: ‘full_name’, ‘klass’ (values are strings).

  • a sequence of strings: <full_name>, <class>

Examples:

pool.CreateInstrument(['/OH', 'NXhutch'])
pool.CreateInstrument(['/OH/Mono', 'NXmonochromator'])
pool.CreateInstrument(['/EH', 'NXhutch'])
pool.CreateInstrument(['/EH/Pilatus', 'NXdetector'])

Returns:

None

CreateElement(argin)[source]

Tango command to create element (motor, counter/timer, 0D, 1D, 2D, IORegister).

Parameters:

argin (list<str>) –

Must give either:

  • A JSON encoded dict as first string with:
    • mandatory keys: ‘type’, ‘ctrl_name’, ‘axis’, ‘name’ (values are strings).

    • optional keys:
      • ’full_name’ : a string representing the full tango device name

  • a sequence of strings: <type>, <ctrl_name>, <axis>, <name> [, <full_name>]

Examples:

data = dict(type='Motor', ctrl_name='my_motor_ctrl_1', axis='4', name='theta',
            full_name='BL99/EH/THETA')
pool.CreateElement([json.dumps(data)])

pool.CreateElement(['Motor', 'my_motor_ctrl_1', '1', 'phi', 'BL99/EH/PHI'])

Returns:

None

RenameElement(argin)[source]

Tango command to rename the element (rename Pool element and put new alias in the Tango Database).

Parameters:

argin

Two elements sequence of strings: <old element name>, <new element name>

Returns:

None

CreateMotorGroup(argin)[source]

Tango command to create motor group.

Parameters:

argin (list<str>) –

Must give either:

  • A JSON encoded dict as first string with:
    • mandatory keys: ‘name’, ‘elements’ (with value being a list of moveables)

    • optional keys:
      • ’full_name’: with value being a full tango device name

  • a sequence of strings: <motor group name> [, <element> ]”

Examples:

data = dict(name='diffrac_motor_group', elements=['theta', 'theta2', 'phi'])
pool.CreateMotorGroup([json.dumps(data)])

pool.CreateMotorGroup(['diffrac_mg', 'theta', 'theta2' ])

Returns:

None

CreateMeasurementGroup(argin)[source]

Tango command to create measurement group.

Parameters:

argin (list<str>) –

Must give either:

  • A JSON encoded dict as first string with:
    • mandatory keys: ‘name’, ‘elements’ (with value being a list of acquirables)”

    • optional keys:
      • ’full_name’: with value being a full tango device name

  • a sequence of strings: <motor group name> [, <element> ]”

An acquirable is either a sardana element (counter/timer, 0D, 1D, 2D, motor) or a tango attribute (ex: sys/tg_test/1/short_spectrum_ro)

Examples:

data = dict(name='my_exp_01', elements=['timer', 'C1', 'sys/tg_test/1/double_scalar'])
pool.CreateMeasurementGroup([json.dumps(data)])

pool.CreateMeasurementGroup(['my_exp_02', 'timer', 'CCD1', 'sys/tg_test/1/short_spectrum_ro'])

Returns:

None

on_pool_changed(evt_src, evt_type, evt_value)[source]
DeleteElement(name)[source]

Tango command to delete element.

Parameters:

argin (str) – name of element to be deleted

Returns:

None

GetControllerClassInfo(names)[source]

Tango command to get detailed information about a controller class.

Parameters:

argin (str) –

Must give either:

  • A JSON encoded list of controller class names

  • a controller class name

Examples:

data = "DummyMotorController", "DummyCounterTimerController"
pool.GetControllerClassInfo(json.dumps(data))
pool.GetControllerClassInfo("DummyMotorController")

Returns:

a JSON encoded string describing the controller class

Return type:

str

ReloadControllerLib(lib_name)[source]

Tango command to reload the controller library code.

Parameters:

argin (str) – the controller library name (without extension)

Returns:

None

ReloadControllerClass(class_name)[source]

Tango command to reload the controller class code (reloads the entire library where the class is described).

Parameters:

argin (str) – the controller class name

Returns:

None

Stop()[source]

Stops all elements managed by this Pool

Parameters:

argin – None

Returns:

None

Abort()[source]

Aborts all elements managed by this Pool

Parameters:

argin – None

Returns:

None

SendToController(stream)[source]
GetFile(name)[source]
PutFile(file_data)[source]
GetControllerCode(argin)[source]
SetControllerCode(argin)[source]

PoolClass

Inheritance diagram of PoolClass
class PoolClass(name)[source]

Bases: DeviceClass
